High-Performance Programmable Power Supply Series: 5A to 50A at 32V Constant Voltage

Overview

Our universal programmable DC power supply units deliver consistent 32V output across a broad current spectrum from 5A to 50A. Engineered for industrial-grade applications requiring precision voltage regulation and adjustable current supply, this modular series offers unparalleled flexibility in electronic testing, charging systems, and Core Specifications

• Output Voltage: 32VDC (±0.5% voltage stability)
• Current Range Configurations:
• Standard Models:

  • 05A (5A)
  • 10A
  • 15A
  • 20A
  • 25A
  • 30A
• High-Capacity Models:

  • 40A
  • 50A
• Operating Modes: Constant Voltage (CV), Constant Current (CC), Voltage Priority Mode
• Ripple Noise: <10mVrms load at 230VAC input)
• Thermal Management: Intelligent fan control with over-temperature protection

Key Technical Advantages

1. Precision Voltage Regulation

Maintains 32V output with ±0.5% deviation under dynamic loading conditions, crucial for sensitive instrumentation and prototype validation.

2. Multi-Stage Current Versatility

• 5A-25A units: Ideal for benchtop R&D, PCB validation, and laboratory environments
• 30A-50A units: Engineered for industrial automation, battery formation systems, and high-power LED arrays

3. Advanced Protection Circuitry

• Over Voltage Protection (OV Over Current Protection (OCP)
• Short Circuit Protection (SCP)
• Soft-start function (500ms ramp-up)

4. Control Interface Flexibility

• Standard RS485 communication (Modbus-RTU protocol)
• Analog 0-5V/0-10V control signal compatibility
• Optional Ethernet/IP connectivity for Industry 4.0 integration

Application Domains

• Automated Test Equipment (ATE)
• Electroplating/power coating systems
• DC motor drive testing
• Telecommunication power backup
• Renewable energy simulator systems
• Semiconductor device aging tests

Compliance & Safety

Certified according to international standards including:

• IEC/)
• UL 61010-1 (Safety)
• RoHS3 Directive compliance

Packaging & Interfaces

• 19" rack-mountable form factor
• Front-panel OLED status display
• Removable terminal blocks with torque protection

IMPORTANT: Specify required amperage during ordering (5A/10A/15A/20A/25A/30A/40A/50A). All models share identical dimensional footprint and control protocols, enabling seamless system scalability. Contact our technical team for current-derating curves at elevated ambient temperatures.
